PRODUCT
Trade Description
Product Feature
n 16-bit DSP
n 4-Stage Pipeline , 1T instruction cycle
n System clock : 32K ~ 33M Hz
n 2M Hz RC ( ±0.5%)
n PLL
n 32K Bytes OTP
n 8K Bytes SRAM
n 40-bit MAC register
n MAC signed / unsigned saturation arithmetic
n ALU signed saturation arithmetic
n 16-bit Timer
n two 14-bit Timers
n three 8-bit/10-bit PWM I/O
n two OP amplifiers
n Tone Generator / Audio Interpolation
n 2.6/2.8/3.0/3.2V programmable LDO
n 4-level LVD
n maskable / non-maskable WDT
n master SPI interface
n 16-bit DAC
n programmable PWM resolution : 10/11/12 bits
n working voltage : 2.4~5.1V
n standby current < 2 uA
