Product Feature

 The H5AV41 is defined to integrate basic applications, for diverse speech algorithms and MCU field. It provides a high-performance and stable computing platform, and lower power consumption to achieve the best SoC solution with the lowest cost architecture.

Product Description

n  Built-in 8bit MCU(Mini-Jupiter).

n  System clock speed 24MHz(Typical 12 MHz).

n Built-in 1Mbit (128 K Bytes)OTP memory.

n  Built-in 2Kbit(256 Bytes) SRAM.

n Built-in R/C Trim(accuracy 1.5%) base clock.

n Built-in  PWM (for Speaker with 10/11 bit resolution).

n  Built-in 2 set of 8 bit Timer， Timer0 and Timer1(Can be configured to 16bit Timer.

n  Built-in 16 of general purpose I/O，P0[0:7] wake-up function，and 4 for High Sink (20mA).

n  Built-in low voltage reset(LVR).

n  Built-in Watch-Dog Timer(WDT).

n  Built-in PWM 8Ω/0.18W Speaker Amplifier(Buzzer)，driving current 2 level (1 & 3/4) .

n  Built-in 10bit Current DAC.

n  Operating voltage 2.4V~5.1V.

n  Standby current : 2uA(Vcc<4.5V)~3uA(4.5V<Vcc<5.1V).

n  Operating Temperature  :

-    -25℃~85℃

n  Memory Storage Reliability:

-    -25℃~85℃
